A06B-0373-B675#7075 Alpha 2/3000 Servo motor with Straight Shaft

Buy online your Alpha 2/3000 Servo motor with Straight Shaft reference A06B-0373-B675-7075 from US e-store Cnc-shopping USA, specialist in CNC machine-tools spare parts.

This FANUC A06B-0373-B675-7075 is a FANUC Alpha 2/3000 AC servo motor designed for precision feed-axis and positioning applications on CNC machine tools equipped with FANUC Alpha drive systems. With a rated power of 0.5 kW and a maximum speed of 3,000 rpm, it is suitable for light- to medium-duty axes on CNC lathes, vertical machining centers and auxiliary motion systems.

The motor features FANUC serial feedback for precise closed-loop control when paired with a compatible FANUC servo amplifier. Its straight-shaft configuration facilitates mechanical coupling to ball screws, gear stages and other drive mechanisms requiring this shaft design. The A2/3000 A64 BRAKE STRAIGHT SHAFT IP67 SEALED configuration also includes an integrated brake, IP67 protection and a sealed construction for industrial environments.

The motor is rated at 0.5 kW, 2.6 A, 129 V armature voltage, 2.0 Nm stall torque and a maximum speed of 3,000 rpm. It can be used on X, Y and Z feed axes, tool changers, loading systems, precision slides and auxiliary mechanisms where accurate positioning, smooth motion and repeatable operation are required.

The complete reference A06B-0373-B675-7075 should be verified before replacement to maintain the original mechanical, electrical and feedback characteristics. The #7075 option identifies a specific factory configuration and should be matched for a proper like-for-like replacement or retrofit application.

Manufactured in Japan, this FANUC servo motor is suitable as a CNC replacement motor, industrial spare part, replacement unit or emergency spare. It is particularly useful for maintenance and retrofit work on older FANUC Alpha installations where a fast and reliable replacement is required.

Each motor supplied by Cnc-shopping is a tested unit and can be checked on suitable CNC test equipment with a compatible servo amplifier when applicable. Products are securely packaged for industrial transportation, with additional protection for the shaft and connectors. Units can be supplied with a commercial warranty, fast dispatch depending on availability, worldwide shipping, repair service, exchange service and obsolete-part sourcing.

Frequently asked questions about A06B-0373-B675-7075:

Is this motor compatible with FANUC Alpha servo amplifiers?
Yes, it is built for use with FANUC Alpha series amplifiers. For a drop-in replacement, match the full code including the suffix so electrical and feedback characteristics remain identical to the original motor.

What output interface does this version use?
This reference features a straight shaft suited to coupling-based connections to ball screws or gear stages. It is preferred where a non-tapered interface is required during service or retrofit.

Does the motor include the feedback device?
FANUC Alpha motors are supplied with integrated serial feedback. Resolution and specific options follow the exact build code, so confirm against the motor nameplate and your CNC/drive pairing.

How should I confirm it is a drop-in replacement for my axis?
Verify the complete reference on your existing unit and compare mechanical interface, connector orientation and option code. This ensures the replacement unit preserves axis tuning and cable compatibility.

What lead time should I expect?
Dispatch is typically within three days depending on availability and final testing. Contact us for current stock status or to arrange a refurbished unit or repair route if needed.
