A06B-6100-H001 Fanuc RJ3 Robot 6axis drive
Starting at $4,440.00 $4,440.00
Buy online your A06B-6100-H001 Fanuc RJ3 Robot 6axis drive reference A06B-6100-H001 from our US e-store Cnc-shopping USA, specialist in CNC machine-tools spare parts.
This FANUC multi-axis servo amplifier is used on RJ3 robot systems to regulate current, torque and speed for joints J1 through J6 with closed-loop feedback. It receives commands over a fiber-optic interface from the robot controller and provides the matched power and control stages needed for stable axis motion. Commonly sourced as a replacement unit for legacy S-430iF, S-430iR/130 and M-710i robots, it meets day-to-day MRO requirements for repair, retrofit and field swap scenarios.
Within the RJ3 architecture the amplifier links controller fiber channels to the servo motor power outputs while managing current control for each axis. The assembly integrates a A20B-2003-0131 power stage with a matched A16B-2100-0200 control board, a pairing that helps avoid nuisance alarms after a drive exchange and keeps axis behavior consistent when the controller re-enables motion.
Fiber signaling between controller and amplifier provides noise immunity on busy production floors, which is important around weld cells and handling lines. The unit is manufactured in Japan and follows the RJ3 generation’s cabling and mounting pattern, so a like-for-like swap is straightforward when replacing a failed channel that reports overcurrent, DC link or fiber link faults. Internal revisions may list additional board references such as A20B-2002-0711 depending on build.
Reference: A06B-6100-H001
Manufacturer: FANUC
Product type: FANUC Servo amplifier A06B-6100 series
Main function: Six-axis servo amplification for RJ3 robots with fiber-optic command link and closed-loop current regulation to each joint motor.
Applications: RJ3-based FANUC robots including S-430iF, S-430iR/130 and M-710i used for handling, assembly and welding tasks.
Key technical data: Complete 6-axis assembly including A20B-2003-0131 power board and A16B-2100-0200 control board, optical fiber interface to the RJ3 controller, Japan manufacture. Internal board identifiers may vary by revision. Fast dispatch options available depending on inventory.
In maintenance practice this module is selected to restore robot motion without redoing axis tuning since parameters reside in the controller. Keeping a stocked spare for this exact reference shortens recovery time when a channel trips hard faults, and a matched assembly helps protect servo motors and gear trains from unstable torque after a field swap. During planned overhauls it can be installed alongside motor or gearbox changes to return the robot to service with minimal retest time.
Units can be supplied as a tested unit or refurbished unit. Our engineers verify operation on dedicated robot and CNC simulators with paired servo motors, checking fiber communication, channel enable, current regulation and alarm reporting. Packaged with ESD protection in robust industrial cartons and covered by warranty as stated for this reference. Many stocked items ship directly from our Florida facility.
For obsolete part coverage or emergency downtime events, this reference is commonly used as an emergency spare. Cnc-shopping USA supports exchange service and repair service to keep older FANUC installations running, which helps extend equipment life and stabilize legacy robot availability.
Frequently asked questions about A06B-6100-H001:
Is it a drop-in swap for RJ3 robots like S-430iF, S-430iR/130 and M-710i?
If your robot originally used this reference, it is typically a direct replacement with existing cabling and fiber links. The RJ3 controller will manage axis parameters after installation.
Does the assembly include the internal control and power boards?
Yes, it comes complete with the A20B-2003-0131 power stage and A16B-2100-0200 control board, avoiding board transplant from a failed drive.
How does it communicate with the controller?
Command and feedback are handled through a fiber-optic interface, which provides reliable signaling in electrically noisy environments.
Will retuning be required after replacement?
Axis tuning values are managed in the RJ3 controller, so a like-for-like swap of this reference does not usually require drive-side parameter work.
Can it be supplied as a refurbished unit with verification?
Refurbished and exchange options are available, tested on simulators with servo motors prior to dispatch to reduce installation time on site.
| Availability | Shipment within 3 days |
|---|---|
| Weight | 20.00 kgs |
-
