A20B-2902-0060 SMD Fanuc 16MB 16TB Servo Module

FANUC Servo module interface board reference FANUC A20B-2902-0060 for the 3rd ou 4th axis of your CNC Machine-Tools. Installed on FANUC Main CPU  system 16MB, 16TB or Fanuc 18MB/18TB. This FANUC SMD Module is tested on our Fanuc test rigs. Ready to be installed and replace your defective module. This FANUC Servo module fits on the slot 7 of your FANUC Main CPU type (A16B-3200-0010, A16B-3200-0170 or other Main CPU comaptible),  SERVO Module also fitts on  FANUC Option board type A16B-2202-0400, A16B-2202-0401 and the other option board of Fanuc 16/18 Model B. This FANUC Servo Interface module A20B-2902-0060 comes with a warranty.

The FANUC Servo module TYPE FANUC A20B-2902-0060 might be faulty and needs to be replaced for the Fanuc alarm code : Alarm 301,  Alarm 302, Alarm 303, Alarm 304, Alarm 305, Alarm 920, Alarm 921, Alarm 922, Alarm 923, Alarm 924. Replace the module corresponding to the axis indicated by the alarm, as shown in the figure below. Please make sure of your diagnostics, it might be also your FANUC Absolute pulse coder, your Absolute coder cable or your Main CPU.
