A20B-3300-0260 Fanuc CPU Pentium Dual Check Safety

Starting at $999.00 $999.00

Product condition Availability Warranty
Price
Refurbished
Ships from: USA Warehouse
stock available Immediate shipment Estimate my delivery
3 months Warranty - Factory return he product is under warranty for a factory return to our workshop, to be repaired or replaced, throughout its warranty period.
$999.00 $999.00
New
Ships from: USA Warehouse
stock available Immediate shipment
12 months Warranty Replacement The product's warranty covers replacement with the same or a similar product for the entire contractual period.
$1,165.50 $1,165.50
Your savings on Manufacturer's suggested retail price: $930.00
Estimate Totals

Enter your destination to get a totals estimate.

  • Top-quality products backed by a warranty
  • Advanced technical support
  • Secure payment process with PDF invoice

Buy online your A20B-3300-0260 Fanuc CPU Pentium Dual Check Safety reference A20B-3300-0260 from our US e-store Cnc-shopping USA, specialist in CNC machine-tools spare parts.

This FANUC i Series CPU assembly is a Pentium based board with integrated Dual Check Safety that supervises axis and spindle motion inside the control. It is used as the processing core for safety cross checking and motion supervision on 16i, 18i, 20i and 21i controls, including 160i, 180i and 210i variants. Commonly sourced as a replacement unit or spare part, it helps maintenance teams restore machine uptime on installed FANUC i Series equipment.

The board employs two independent processing paths that validate speed and position data for the CNC axes and spindle. When a mismatch is detected, redundant outputs command MCC OFF to cut drive power. This internal cross checking helps reduce reliance on multiple external safety relays while keeping fast detection and clear stop commands within the control.

In typical cabinets it mounts on the loader PCB inside the yellow base unit and accepts a DRAM module sized to the control configuration. The assembly is widely encountered on machining centers, turning machines and grinders running i Series controls paired with FANUC servo drives and spindle amplifiers. Technicians use this model where monitored setup moves are needed with doors open under supervised speed and position limits.

In service contexts it is ordered as a drop-in replacement when the control will not boot, raises safety related alarms or shows intermittent resets traced to CPU faults. Keeping a tested unit in the industrial spare inventory helps shorten repair turnaround and reduces machine downtime.

Reference: A20B-3300-0260

Manufacturer: FANUC

Product type: FANUC i Series CPU board with integrated Dual Check Safety for 16i, 18i, 20i, 21i including 160i, 180i, 210i families

Main function: Pentium based processing with dual channel motion supervision and redundant power cut outputs for CNC safety monitoring

Applications: Machining centers, lathes and grinders using FANUC i Series controls, field replacement for non booting or safety alarmed systems, stocked spare for preventive maintenance

Key technical data: Two independent CPUs cross check axis and spindle data, MCC OFF via redundant outputs, installs on the loader board in the yellow base unit, accepts DRAM per system build, manufactured in Japan, works with FANUC servo and spindle amplifier systems

For replacement, match the part code on the nameplate and confirm the target control series. Back up parameters and system data before swap, then plan a controlled restart and safety validation by qualified personnel. Many shops keep a refurbished unit or a verified spare on the shelf to protect uptime on legacy i Series machines.

Units are verified on appropriate CNC test benches and simulators by skilled engineers, then packed in ESD safe materials with protective foam for industrial shipping. Warranty terms are provided with the order. Many stocked items ship directly from our Florida facility, with fast dispatch depending on availability.

This item can be used as an emergency spare part to reduce unexpected downtime on older installations. Cnc-shopping USA supports sourcing of obsolete parts for FANUC controls and can offer repair service or exchange service depending on condition and availability to extend machine life with reliable CNC replacement components.

Frequently asked questions about A20B-3300-0260:

Which FANUC controls does this board support?
It is designed for FANUC i Series controls used on 16i, 18i, 20i and 21i families, including 160i, 180i and 210i variants. Always confirm the code on the original board and the control configuration before ordering.

Where is it installed in the cabinet?
It is typically fitted on the loader PCB inside the yellow base unit. Slot position follows the internal layout of the specific i Series model.

Does it require separate memory?
Yes. The A20B-3300-0260 CPU Module assembly accepts a DRAM module matched to the machine’s system build. Use the correct capacity and type to mirror the original configuration. (Follow your existing configuration)

Is this a field replaceable part?
Yes. After installation the control may need system restore, parameter loading and safety checks by qualified personnel before returning the machine to service.

Do you support repair or exchange?
Cnc-shopping USA can evaluate repair service or provide an exchange service depending on condition and availability. Share the fault description and the board code for assessment.
