ABB 3HNE00313-1 Teach Pendant Panel unit TPU2 S4C

Buy online your ABB 3HNE00313-1 Teach Pendant Panel unit TPU2 S4C reference 3HNE00313-1 from our US e-store Cnc-shopping USA, specialist in CNC machine-tools spare parts.

This handheld ABB TPU2 programming panel is a field-ready operator interface for ABB IRB robots using S4C and S4C+ controllers. It serves as the main programming and jogging terminal, used for point teaching, menu navigation and service tasks. A practical replacement unit for maintenance teams, it is commonly sourced as a spare part to keep robotic cells running with minimal downtime.

The 3HNE00313-1 is designed for IRB installations equipped with S4C M97-M99 and S4Cplus M2000 control cabinets. It connects through the dedicated pendant interface using the supplied cable and keyed connector. In most cases it is a drop-in replacement when matching the existing TPU2 specification on the robot cabinet, which simplifies field replacement during breakdowns or planned maintenance.

This unit features an LCD display with backlight for clear readability on the production floor. It includes the integrated emergency stop and a side HMI switch as required for safe manual operation during teach mode. Keypad functions support axis jog, data entry and navigation through the S4C family menus, which is essential for commissioning steps, program edits and recovery procedures.

Typical use cases include restoring a robot that has a dim or failed screen, unresponsive keys or a damaged cord. Keeping one tested unit in on-site spare inventory is a common strategy to reduce repair turnaround and avoid extended machine downtime. The pendant can be installed as a fast field replacement to bring the IRB back online while the faulty pendant is sent for repair service or evaluation.

Reference: 3HNE00313-1

Manufacturer: ABB

Product type: ABB ROBOTICS

Main function: Handheld programming and jogging interface for ABB IRB robots on S4C and S4C+ controller platforms

Applications: Commissioning, point teaching, manual jogging, program adjustment and maintenance recovery on ABB IRB systems using S4C family controllers

Key technical data: TPU2 teach pendant with LCD backlit display, integrated emergency stop and side HMI switch, supplied with cable and dedicated connector, compatible with ABB S4C M97-M99 and S4Cplus M2000 controllers, manufactured in Sweden. Many stocked items ship directly from our Florida facility depending on availability.

For day-to-day industrial service, this model is used to jog axes in teach mode, verify I/O, adjust parameters and load or modify programs on S4C and S4C+ systems. It is frequently selected as a drop-in replacement when the existing pendant has a worn keypad or display fault. Keeping a pendant in industrial spare inventory helps maintenance teams shorten unplanned stoppages and maintain machine uptime across multiple identical IRB cells.

Units are inspected on appropriate ABB robot control test benches or simulators by skilled engineers. Display, keypad matrix, emergency stop, communications and cable integrity are verified where applicable. Each unit is securely packed for industrial shipping and supplied with warranty. Depending on availability, products are commonly dispatched from our Florida warehouse.

This model supports legacy S4C and S4C+ installations that are still in service. Cnc-shopping USA can assist with refurbished unit sourcing, exchange service options and repair service for obsolete robot parts, helping extend the operating life of older IRB platforms and reduce unexpected downtime.

Frequently asked questions about 3HNE00313-1:

Is this TPU2 compatible with both S4C and S4Cplus controllers?
Yes, it is intended for ABB IRB robots using S4C M97-M99 and S4Cplus M2000 control cabinets. Match the installed pendant type and connector before ordering.

Does the unit include the cable and connector?
It is supplied with the cable and dedicated connector. Compare your installed connector to the product photos and your cabinet interface to confirm fit.

Is installation plug and play on an IRB with S4C or S4C+?
In most cases it is a direct replacement when the existing system uses the same TPU2 specification. Power down per plant procedure, swap the pendant, then power up and verify operation.

Can this replace a pendant with a failed LCD or worn keys?
Yes, it is commonly used to replace pendants with defective displays, unresponsive keys or damaged cords, restoring robot operation quickly.

Are repair or exchange options available for a faulty pendant?
Cnc-shopping USA can support repair or exchange programs depending on condition and availability. A tested replacement unit can be supplied to minimize downtime while your core is evaluated.
