DECA D16LAT1-1ab Switch 2 positions lamp ORANGE PUSH Rectangular

DECA switch two positions with lamp (ORANGE Version) , rectangular (18x24mm) 16 mm diameter for CNC Machines Operator panel. The reference of this switch is  D16LAT1-1ab.

This switch has one NO contact and one NC conctact. The Voltage of  the lamp MIDGET 3/4  is 28V DC 20mA. For a voltage of  250V AC, the maximum current: 5A. This DECA switch D16LAT1-1ab is ready to be installed on your operator panels  FANUC, MAZAK, HURCO...

A DPDT switch has six connections, but since polarity reversal is a very common usage of DPDT switches, some variations of the DPDT switch are internally wired specifically for polarity reversal. These crossover switches only have four terminals rather than six. Two of the terminals are inputs and two are outputs. When connected to a battery or other DC source, the 4-way switch selects from either normal or reversed polarity. Such switches can also be used as intermediate switches in a multiway switching system for control of lamps by more than two switches. DECA D16LAS1-1ab
