HEIDENHAIN ROD 426.0013 5000 pulses Encoder Integrated connector
Starting at $421.80 $421.80
Product condition Availability Warranty
Price
Estimate my delivery
HEIDENHAIN Incremental encoder type ROD 426.0013 5000 pulses (12pins Connector on the pulse coder cover) for sale online on Cnc-shopping website. HENDEIHAIN Encoder Stub shaft diameter 6 mm with integrated 12 pins connector to plug on your system such as Servo motor or any measuring equipment. This is an incremental encoder type HEIDENHAIN ROD426 5000 pulses/rev. The encoder is ready to set and replace your defective encoder on your CNC Machine-tools or other equipment. HEIDENHAIN ROD 426 5000 pulses comes with a warranty.
HEIDENHAIN ROD426.0013 - 5000 pulses Id.Nr. 254048-34
Industrial standard incremental rotary encoder with integral bearing and separete chaft coupling with 5v TTL Quadrature output and synchro flange. HEIDENHAIN's ROD family of rotary encoders are characterized by their rugged design and compact dimensions. ROD 426 encoders are coupled to the drive or the spindle via a separate rotor coupling. Axial motion and misalignment (radial and angular offset) between the encoder shaft and the drive shaft are compensated by the coupling. The ROD 426 has a synchro flange for mounting. HEIDENHAIN ROD426.0013 - 5000 pulses
Availability | Immediate shipment |
---|---|
Weight | 1.00 kgs |
