HEIDENHAIN UM111D Single Axis Power Servo drive Id. 667945-01
Starting at $2,497.50 $2,497.50
Buy online your HEIDENHAIN UM111D Single Axis Power Servo drive Id. 667945-01 reference UM111D from our US e-store Cnc-shopping USA, specialist in CNC machine-tools spare parts.
This HEIDENHAIN single-axis power module is used within TNC-controlled machine tools to drive one servo axis with stable current regulation and precise response. It operates as the power stage between the control loop and the servo motor, making it a practical replacement unit or spare part for service teams maintaining legacy HEIDENHAIN-based systems. Commonly sourced for field replacement, retrofit work and MRO spare inventory, it helps restore axis motion after amplifier faults or aging failures.
Within the control architecture, the UM111D accepts command and feedback signals from the HEIDENHAIN control chain and delivers controlled motor current for a single feed axis. With a rated output of 1 x 7.5 A, it is well suited to light and medium-duty axes found on milling, turning and grinding machines using TNC platforms. The compact 50 mm module width saves cabinet space and makes side-by-side mounting straightforward in crowded electrical enclosures.
Thermal load is modest at approximately 70 W power loss, which supports reliable operation in ventilated control cabinets when airflow and heat management are maintained to machine specifications. Control electronics draw 120 mA at DC 15 V and 70 mA at DC 24 V, so the cabinet’s auxiliary supplies must be in good condition. For best results during a drop-in replacement, match the Id. 667945-01 designation and follow the machine documentation for rack position, connectors and grounding.
The UM111D is found in production floors where HEIDENHAIN TNC controls are installed and where stable, repeatable axis motion is required. Maintenance teams use it to recover from amplifier trips, intermittent axis faults or complete drive failures, keeping machine uptime on schedule. It is a solid option for refurbished unit sourcing, retrofit planning and preventive spare holding when supporting older HEIDENHAIN installations.
Reference: UM111D
Manufacturer: HEIDENHAIN
Product type: HEIDENHAIN TNC Controls - Digital Readout
Main function: Single-axis power stage driving one servo motor under TNC command for precise feed-axis control
Applications: Axis amplifier replacement on HEIDENHAIN-equipped mills, lathes and grinders, retrofit projects, stocked MRO spare for legacy TNC systems
Key technical data: Rated output 1 x 7.5 A; compact 50 mm module width for cabinet integration; typical power loss about 70 W; control supply draw approx. 120 mA at DC 15 V and 70 mA at DC 24 V
For maintenance scenarios, this module serves as a direct service swap to restore axis movement after drive alarms or failure. Many teams keep a tested unit on the shelf to cut repair turnaround and reduce machine downtime. When planning retrofits or cabinet work, confirm rack slotting and connector orientation, then re-commission the axis per the machine’s TNC parameters.
Units are tested on CNC simulators with servo motors by skilled engineers, then packed for industrial shipping with ESD-safe handling. A warranty is included. Many stocked items ship directly from our Florida facility, with fast dispatch depending on availability.
Cnc-shopping USA supports emergency spare sourcing for obsolete HEIDENHAIN electronics. Repair service and exchange service may be available for this series, helping extend the lifetime of installed machines and reduce unplanned downtime. We can also assist with locating obsolete parts or suitable replacement units from surplus inventory when available.
