HEIDENHAIN UM113D Spindle drive Axis module 40A/80A - 56A/80A Id. 730435-01
Starting at $2,941.50 $2,941.50
Buy online your HEIDENHAIN UM113D Spindle drive Axis module 40A/80A - 56A/80A Id. 730435-01 reference UM113D from our US e-store Cnc-shopping USA, specialist in CNC machine-tools spare parts.
This HEIDENHAIN module is used in TNC-controlled machine tools to power and regulate both feed axes and spindle channels within the drive rack. It serves as a field replacement for aging or faulty units in HEIDENHAIN drive systems, supporting machine uptime on production floors that rely on stable spindle acceleration and consistent axis torque delivery.
The UM113D manages power stages for an axis channel and a spindle channel within compatible HEIDENHAIN cabinets, providing defined current capability labeled 40A/80A and 56A/80A as per the model marking. Its air-cooled design helps maintain thermal stability in enclosed control cabinets when ventilation is correctly maintained. The identification code 730435-01 is important for matching hardware during service interventions and for confirming rack-level compatibility.
Typical use cases include CNC lathes, machining centers and grinding machines equipped with HEIDENHAIN TNC controls and coordinated digital drives. In practice, technicians install the unit as a drop-in replacement, reuse existing power and control connectors from the rack, and then bring the machine back online once the control confirms drive enable. Power loss figures of 280 W on the axis channel and 430 W on the spindle channel indicate the thermal load that must be considered by maintenance when checking panel airflow.
Control-side consumption values of 170 mA / 360 mA reflect the module’s demand on the internal supplies that service the drive electronics. The air-cooling requirement is straightforward for most cabinets and aligns with standard HEIDENHAIN rack ventilation, which is common in retrofit and service scenarios where panel space is fixed and only the failed module is exchanged.
Reference: UM113D
Manufacturer: HEIDENHAIN
Function: Spindle and axis power module for HEIDENHAIN drive racks used with TNC-controlled machine tools
Identification: Id. 730435-01 for hardware matching during replacement
Cooling: Air cooled for cabinet installation
Typical electrical data: Control consumption 170 mA / 360 mA, power loss 280 W (axis channel) and 430 W (spindle channel)
Marking on unit: 40A/80A and 56A/80A capability as designated on the model label
Origin: Made in Germany
In the field this unit is commonly swapped during unplanned stops caused by drive faults, spindle enable errors or axis power-stage alarms. Maintenance teams often keep at least one replacement unit on the shelf to cut repair turnaround, especially on legacy machines where sourcing time matters. For planned overhauls, it is frequently used in preventive changeouts to stabilize performance before peak production runs.
Each item is a tested unit verified by skilled engineers on CNC simulators with servo motors to validate enable, control interface response and thermal behavior under load. Units are packed for industrial shipping and supplied with a commercial warranty from Cnc-shopping USA. Many stocked items ship directly from our Florida facility, depending on availability.
When a machine is down this module serves as an effective emergency spare to restore operation quickly. Cnc-shopping USA supports obsolete part sourcing for HEIDENHAIN drive modules, along with repair service and exchange service options that help keep older TNC installations running without a full retrofit.
Frequently asked questions about UM113D:
What do the 40A/80A and 56A/80A markings represent on the UM113D label?
They indicate the current capability ranges associated with the axis and spindle channels as defined by the module variant. Use these markings and the Id. 730435-01 code to confirm suitability with the drive rack and the motor sizing on your machine.
Is the UM113D compatible with HEIDENHAIN TNC-controlled machines using standard drive racks?
Yes, it is designed for HEIDENHAIN drive cabinets used with TNC controls. Match the module Id. 730435-01 and rack documentation to verify form, fit and electrical interface against your original part.
Does replacement require parameter transfers after installation?
In most cases parameters are managed by the CNC control or existing memory in the drive system. Plan to back up machine data and confirm drive enable and direction checks as part of your standard commissioning process.
What should be considered regarding cooling in the control cabinet?
The UM113D is air cooled, so cabinet ventilation must be unobstructed and fans should be in working order. The listed power loss values help maintenance estimate thermal load when assessing airflow in older panels.
