HEIDENHAIN UM115D Spindle drive Axis module 96A/192A - 125A/192A Id. 671566-01
Starting at $3,219.00 $3,219.00
Buy online your HEIDENHAIN UM115D Spindle drive Axis module 96A/192A - 125A/192A Id. 671566-01 reference UM115D from our US e-store Cnc-shopping USA, specialist in CNC machine-tools spare parts.
This HEIDENHAIN power module supports spindle and axis power stages in TNC-driven machine tools, providing the controlled output needed for high-current spindle operation and heavy feed axes. It is a professional-grade replacement unit for HEIDENHAIN motion systems and a reliable CNC replacement component for maintenance teams managing downtime on production floors.
The UM115D integrates within HEIDENHAIN drive racks to deliver regulated current to the spindle or axes while coordinating with the motion controller. Current classes 96A/192A and 125A/192A cover demanding spindle starts and load transitions often seen in milling, turning, and grinding applications. With specified power losses of 610 W on axis service and 870 W on spindle service, proper cabinet airflow is essential, which is why this module is designed for Cooling Air operation.
The module identified as Id. 671566-01 is commonly installed in HEIDENHAIN-based machine tools using TNC controls and matching UM-series drive hardware. It is suited for field replacement where matching form factor and rating alignment allow a straightforward swap, minimizing rework in the electrical cabinet. Technicians typically verify the installed current class against the original plate to maintain consistency with the machine’s motor and drive configuration.
Typical use cases include restoring spindle power after drive faults, resolving unstable axis power delivery, and supporting retrofit programs where legacy HEIDENHAIN hardware must remain serviceable. The unit’s 360 mA/460 mA control-side consumption should be considered in cabinet design and diagnostic checks, while the stated thermal losses guide cabinet ventilation and filter maintenance planning.
Reference: UM115D
Manufacturer: HEIDENHAIN
Product type: Spindle and axis power module for HEIDENHAIN motion systems
Identification: Id. 671566-01
Current classes: 96A/192A and 125A/192A
Cooling method: Cooling Air
Control consumption: 360 mA / 460 mA
Power loss: 610 W on axis operation, 870 W on spindle operation
Origin: Made in Germany
Availability: Shipment within 3 days
For maintenance teams, this module is a practical spare part to keep on the shelf for urgent changeouts and scheduled rebuilds. When a machine is down with drive alarms or intermittent spindle power, having a compatible drop-in replacement like the UM115D helps restore uptime quickly and supports preventive strategies on machines approaching overhaul.
Units are tested on CNC simulators with servo motors by skilled engineers before shipping. Packaging is prepared for industrial transport with ESD-safe handling and protective cushioning. Warranty is provided by Cnc-shopping USA. Many stocked items ship directly from our Florida facility, depending on availability.
This item is often used as an emergency spare to reduce unexpected downtime. Cnc-shopping USA supports sourcing obsolete parts, as well as exchange service, repair service, and supply of refurbished units when available, helping legacy HEIDENHAIN installations remain operational.
