HEIDENHAIN UM121D Servo Module Inverter Id.Nr. 392319-01

Starting at $2,453.10 $2,453.10

Manufacturer's Suggested Retail Price (12-2003): $2,500.00
Product condition Availability Warranty
Price
Exchange service
Ships from: USA Warehouse
stock available Shipment within 3 days
6 months Warranty - Factory return he product is under warranty for a factory return to our workshop, to be repaired or replaced, throughout its warranty period.
$2,453.10 $2,453.10
Your savings on Manufacturer's suggested retail price: $290.00
Refurbished
Ships from: USA Warehouse
stock available Shipment within 3 days
4 months Warranty - Factory return he product is under warranty for a factory return to our workshop, to be repaired or replaced, throughout its warranty period.
$3,219.00 $3,219.00
Your savings on Manufacturer's suggested retail price: -$400.00
Estimate Totals

Enter your destination to get a totals estimate.

  • Top-quality products backed by a warranty
  • Advanced technical support
  • Secure payment process with PDF invoice

Buy online your HEIDENHAIN UM121D Servo Module Inverter Id.Nr. 392319-01 reference UM121D from our US e-store Cnc-shopping USA, specialist in CNC machine-tools spare parts.

Built by HEIDENHAIN, this compact two-axis inverter serves as the axis power stage in TNC-controlled machine tools. It drives matched QSY synchronous AC servo motors and closes the current loop for smooth feed-axis motion on milling, drilling and grinding equipment. Commonly sourced as a replacement unit or spare part, it is a practical CNC replacement component for maintenance and retrofit projects. Most products are shipped from our Florida warehouse unless otherwise specified on the product page.

The module manages motor phase currents, torque commands and dynamic braking for two independent axes, keeping axis behavior stable during rapid moves and contouring. The rating 2x9A/18A identifies dual channels with nominal and peak current capacity sized for typical HEIDENHAIN feed drives. Installed in the drive cabinet, it interfaces between the TNC control and the motor windings to ensure reliable axis response under load.

Designed to pair with HEIDENHAIN QSY motors, the unit supports smooth running with low torque ripple when the current loop is correctly matched to the motor. In multi-axis machines it is often deployed across X, Y or auxiliary axes using identical modules, which simplifies service and keeps spare inventory straightforward for maintenance teams.

For field replacement, matching the printed model and Id.Nr. 392319-01 helps ensure the same electrical rating and connector layout. This like-for-like approach reduces commissioning steps, avoids harness changes and restores axis performance quickly after a drive fault.

Reference: UM121D

Manufacturer: HEIDENHAIN

Product type: HEIDENHAIN TNC Controls - Digital Readout

Main function: Two-axis servo inverter powering and regulating paired HEIDENHAIN QSY synchronous AC servo motors on feed axes within a TNC-controlled loop.

Applications: Feed axes on milling, drilling and grinding machines using HEIDENHAIN TNC systems, commonly X and Y axes on legacy or retrofit installations.

Key technical data: Variant Id.Nr. 392319-01, dual output channels rated 2x9A nominal with 18A peak, cabinet-mounted axis power stage interfacing with the CNC for torque command and dynamic braking, designed for HEIDENHAIN QSY servo motors, manufactured in Germany, fast dispatch depending on availability, typically within 3 days.

On the production floor this module is used to recover axis control when existing drives report overcurrent trips, amplifier alarms or unstable following conditions. Maintenance teams favor a like-for-like swap with UM121D to keep wiring, cabinet spacing and thermal behavior consistent, which helps complete the changeover during night or weekend interventions with minimal downtime.

Keeping a tested unit as part of industrial spare inventory supports quick field replacement during urgent breakdowns. For planned retrofits or life-extension projects, using the same Id.Nr. 392319-01 variant keeps electrical characteristics aligned with the original build and limits requalification time.

Each drive can be verified by skilled engineers on CNC simulators with servo motors to check both channels, current response and fault handling before packing. Units are secured in ESD-safe packaging with protective foam for worldwide shipping, and the item is supplied with a warranty for added assurance.

This module is frequently required as an emergency spare to keep older TNC-based machines operational. Cnc-shopping USA supports sourcing of obsolete parts and can offer repair service or exchange service when suitable, helping extend machine life without a full retrofit.
