main product photo

HEIDENHAIN VRZ 403 Position display unit

Be the first to review this product

Starting at $555.00 $555.00

Product condition Availability Warranty
Price
Refurbished
Ships from: FRANCE Warehouse
stock unavailable Available in 5 to 8 days
3 months Warranty - Factory return he product is under warranty for a factory return to our workshop, to be repaired or replaced, throughout its warranty period.
$555.00 $555.00
Contact Us
  • High-quality products with warranty
  • Expert technical service
  • Secure payment and PDF invoice
HEIDENHAIN VRZ 403 (VRZ403) position display unit for sale online on Cnc-shopping to replave your defective module. Output for this HEIDENHAIN VRZ 403 (Id.Nr 230024 01) is through V.24/RS-232C. Counter VRZ 403 in conjunction with gauges MT 12/25/60/101 constitute a HEIDENHAIN-METRO digital length measuring  unit. In addition to the gauges, other HEIDENHAIN linear encoders with 10 um or 20 um grating pitch (e. g. LID  300, LS 703/704, LS 403/404,  ULS  300, etc...) as weil as HEIDENHAIN rotary encoders with sinusoidal output Signals are also suitable for connection. The output Signals of the gauges are amplified, interpolated within the counter and subsequently counted in accordance with the sign. The measured value is displayed via a seven-digit 7-Segment digital display.


The counters are provided with the following functions:

- Zero  reset
- Datum  set
- Reference  mark  evaluation  REF
- mm/inch  calculator
- Selectable  display  step
- Selectable  counting  direction
- Classifying  with  2  limit  values
- Minimum/Maximum  acquisition
- Subtraction  of  Maximum  and  Minimum  (differente)
- Display  stop
- External  Operation
- Output  for  classifying  state

This HEIDENHAIN VRZ 403 (Id.Nr 230024 01) comes with a warranty.

Digital readouts for manual machine tools increase your productivity. You save time, increase the dimensional accuracy of the finished workpiece and enjoy userfriendly operation. It plays no role whether you have equipped a new or used machine with a digital readout. HEIDENHAIN digital readouts can easily be retrofi tted to any model of machine or type of equipment, whatever the application and number of displayed axes. Practice-oriented functions and cycles are available for various applications. The distance-to-go display feature with graphic positioning aid allows you to approach the next nominal position quickly and reliably simply by traversing to a display value of zero. HEIDENHAIN VRZ 403 (Id.Nr 230024 01)
More Information
AvailabilityAvailable in 5 to 8 days
Weight5.00 kgs
