main product photo

INDRAMAT LE5-024 Servo TDM Fan unit 24V

Be the first to review this product

Starting at $166.50 $166.50

Manufacturer's Suggested Retail Price (02-2014): $500.00
Product condition Availability Warranty
Price
Refurbished
Ships from: FRANCE Warehouse
stock available Shipment within 3 days
1 month Warranty Replacement The product's warranty covers replacement with the same or a similar product for the entire contractual period.
$166.50 $166.50
Your savings on Manufacturer's suggested retail price: $350.00
New
Ships from: FRANCE Warehouse
stock unavailable Out of stock
4 months Warranty Replacement The product's warranty covers replacement with the same or a similar product for the entire contractual period.
$310.80 $310.80
Contact Us
Your savings on Manufacturer's suggested retail price: $220.00
  • Top-quality products backed by a warranty
  • Advanced technical support
  • Secure payment process with PDF invoice
INDRAMAT TDM fan unit reference INDRAMAT LE5-24 (LE5-024) for sale online on Cnc-shopping website. INDRAMAT Externally mounted Fan unit for cold-running technology fitted with INDRAMAT TDM AC Servo controllers such as TDM3 or TDM4 units. INDRAMAT LE5-024 powered by the 24VDC directly from the TDM drive unit through the green connector. Current consumption equals 800 mA when the 24V direct current fan unit LE5-024 is connected to the +24V of the servo drive module. INDRAMAT LE5-024 unit for forced ventilation in TDM3.2-030-300-W1 and also the TDM4.1, TDM6.1, TDM7.1 series.


A cooling baffle (INDRAMAT mat. no. 224 869) must be screwed onto the INDRAMAT TDM heatsink on the left side of the unit. (Also see the dimensions sheet for the servo-drive module.) Only this arrangement guarantees that the fan will provide sufficient cooling.

The INDRAMAT LE5-024 Fan unit replaces the following versions : LE5-24-NN LE5-024NN LE5-24NN QL4/0020-4912-4431010 and also the obsolete versions in 115Volts and 220Volts (LE5-115 and LE5-220)
More Information
AvailabilityShipment within 3 days
Weight3.00 kgs
