MITSUBISHI HA200NC-S AC Servo Motor 3.5kW
Starting at $1,554.00 $1,554.00
Buy online your MITSUBISHI HA200NC-S AC Servo Motor 3.5kW reference HA200NC-S from our US e-store Cnc-shopping USA, specialist in CNC machine-tools spare parts.
This MITSUBISHI HA series permanent magnet AC unit is built for closed loop feed-axis motion on CNC equipment where accurate positioning and smooth torque delivery are required. Rated 3.5 kW at 2000 rpm, it serves as a reliable replacement motor or stocked spare for maintenance teams working on legacy machine tools and industrial automation lines.
The motor operates as a feed-axis drive in pairing with compatible MITSUBISHI servo amplifiers. It is supplied without a measuring system and was originally matched with TAMAGAWA OSE or OAER feedback devices, which must be selected to suit the installed amplifier parameters. This configuration supports repeatable positioning on ballscrew or geared axes used in milling, turning and grinding tasks.
Mechanical interfaces are straightforward for field service. A straight 35 mm shaft and a 114 mm centering pilot align with common machine-tool flanges, while front power and feedback connectors keep cabling accessible during changeover. The design runs without external ventilation, which helps maintain a compact body for cabinet or frame-mounted installations. This version is supplied without brake.
In maintenance files the model can also appear as HA200NCS or as a typographical variant HA2OONC-S. Always verify the nameplate and mechanical details before commissioning, then match the feedback option and amplifier settings to avoid startup issues during a drop in replacement.
Reference: HA200NC-S
Manufacturer: MITSUBISHI
Product type: MITSUBISHI AC Servo Motor
Main function: Precision feed-axis drive for CNC positioning and motion control
Applications: CNC lathes, machining centers, grinders and automation stations using compatible MITSUBISHI servo systems
Key technical data: Permanent magnet AC servo rated 3.5 kW at 2000 rpm, compact body without external ventilation, straight 35 mm shaft, 114 mm centering pilot, no brake, delivered without encoder, originally paired with TAMAGAWA OSE/OAER feedback, front power and encoder connectors, made in Japan. Cross references sometimes noted as HA200NCS or HA2OONC-S.
On the production floor this unit is commonly used as a CNC replacement component to recover an axis after encoder faults, winding failures or mechanical damage. Keeping a stocked replacement unit with matching geometry and torque rating helps maintenance teams shorten repair turnaround and stabilize machine uptime on older installations.
Before a planned swap, confirm the installed feedback type and cable orientation, then match amplifier parameters to the selected TAMAGAWA OSE or OAER option. Verifying coupling fit, bolt pattern and shaft keying against the original reduces changeover time and helps avoid unplanned downtime during restart.
Units can be tested by skilled engineers on CNC simulators with servo drives to check electrical integrity, phase balance and feedback interface continuity when equipped. Packaging protects the shaft and connectors for industrial transport, and each unit is supplied with a functional warranty. Many stocked items ship directly from our Florida facility, with worldwide shipping available.
This model is frequently sourced as an emergency spare for legacy machines where the original has become an obsolete part. Cnc-shopping USA can assist with sourcing, and repair service or exchange service may be available depending on condition and inventory, helping extend the service life of installed CNC assets.
Frequently asked questions about HA200NC-S:
Which feedback devices match this motor?
It is delivered without a measuring system and was originally paired with TAMAGAWA OSE or OAER encoders (You can purchase it separately from our estore or put back your existing encoder on the new Servo motor). Select the option that matches your servo amplifier parameters or transfer the compatible unit from your existing motor.
Does this version include a holding brake?
No, this configuration is supplied without a brake. If a brake is required, confirm the needed variant and mounting details before ordering.
What are the primary mechanical interfaces?
The motor uses a straight 35 mm shaft and a front flange with a 114 mm centering pilot. Check the bolt circle and coupling fit against your original unit for a clean drop in.
How do I confirm servo amplifier compatibility?
Match the motor’s 3.5 kW rating and 2000 rpm base speed, then align the amplifier parameters to the chosen TAMAGAWA OSE/OAER feedback. Verifying nameplate data with the drive catalog helps prevent commissioning issues.
Are there alternate references I might see in documentation?
Yes, you may find HA200NCS or the typographical form HA2OONC-S. Always rely on the mechanical details and electrical ratings on the nameplate during replacement.
| Availability | Immediate shipment |
|---|---|
| Weight | 36.00 kgs |
-
