MITSUBISHI MDS-C1-V1-45 Servo Drive Unit 4.5kW
Starting at $1,831.50 $1,831.50
Buy online your MITSUBISHI MDS-C1-V1-45 Servo Drive Unit 4.5kW reference MDS-C1-V1-45 from our US e-store Cnc-shopping USA, specialist in CNC machine-tools spare parts.
This single-axis MITSUBISHI MELDAS MDS-C1 servo amplifier supplies controlled three-phase power to matched HA and HC series servo motors used on many MAZAK machine-tools. Deployed as an axis drive in MELDAS-controlled systems, it handles the power stage and feedback interface required for precise feed motion on machining axes. It is commonly sourced as a drop-in replacement or refurbished unit to restore machine uptime on legacy and current installations.
Built around the 4.5 kW class, this unit is suited to feed axes where stable current delivery, reliable braking control and consistent thermal behavior are essential for positioning accuracy. It receives its main DC bus from the MDS-C1 power supply section and provides a 3-phase output to the motor within the 155 V class. The auxiliary control supply runs on 200 to 230 VAC. Typical applications include X, Y or Z feed axes on turning centers and machining centers where the original MDS-C1-V1-45 was installed.
Field technicians will frequently encounter label variants such as MDS-C1-V1-45-N as well as internal board or pack codes like BND582W000AD, BNP-C3000, B50780 or B50780-1. These references appear in the service ecosystem for MAZAK and other MELDAS-based machines and are useful when verifying a like-for-like replacement unit. When paired with the correct HA or HC motor rating, this drive supports fast repair turnaround with minimal parameter changes during commissioning.
Reference: MDS-C1-V1-45
Manufacturer: MITSUBISHI
Product type: MITSUBISHI Servo drive MDS-C1
Main function: Single-axis servo amplifier for MELDAS systems powering HA/HC series servo motors
Applications: Axis drive for MAZAK and other MELDAS-equipped CNC machine-tools, also used in robotics and conveying cells where MDS-C1 is specified
Key technical data: 4.5 kW class, DC bus input approximately 270 to 311 VDC with auxiliary 200 to 230 VAC 50/60 Hz control supply, 3-phase motor output in the 155 V class with 0 to 240 Hz output frequency, continuous current around 14.5 A with 29 A peak for short overload events, 150% for 1 minute overload capability, forced-air cooling, typical operating range from 0 to 55°C. Common label variants include MDS-C1-V1-45-N, and internal references such as BND582W000AD, BNP-C3000, B50780 and B50780-1.
In day-to-day maintenance, this model is selected to replace a failed axis drive on the production floor without reworking cabinet layouts. It fits the original MDS-C1 mounting and wiring pattern, which helps maintenance teams shorten downtime and return the machine to service. Keeping a stocked spare on site is a common practice for shops running multiple MAZAK units built around MELDAS controls.
The drive is installed in sealed electrical cabinets. Provide adequate ventilation clearance and follow the machine builder’s guidelines for heat extraction to maintain stable operation under continuous duty. For planned outages, many facilities schedule a proactive field replacement using a tested unit to stabilize older axes and extend system lifetime.
Each refurbished MITSUBISHI MDS-C1-V1-45 offered by Cnc-shopping USA is tested on CNC simulators with MITSUBISHI servo motors by skilled engineers. Units are packed with antistatic protection and foam for industrial shipping and supplied with a functional warranty. Many stocked items ship directly from our Florida facility.
For plants supporting legacy equipment, this model is often managed as an emergency spare to cover unexpected failures on older MELDAS lines. Cnc-shopping USA can assist with sourcing obsolete parts, and repair or exchange service may be available to help keep established CNC assets productive.
Frequently asked questions about MDS-C1-V1-45:
Is this unit compatible with MITSUBISHI HA and HC motors?
Yes, it is specified for HA and HC series servo motors when matched to the 4.5 kW class and current rating. Always check the motor nameplate and machine documentation before ordering.
What do variants like MDS-C1-V1-45-N or codes such as BND582W000AD indicate?
They are label or internal assembly references seen on the same family of units. They help confirm a like-for-like replacement during sourcing and do not change the core rating when matched correctly.
What supply does this drive require?
The power section is fed by the MDS-C1 DC bus around 270 to 311 VDC, with an auxiliary control supply of 200 to 230 VAC at 50/60 Hz. Verify the cabinet power architecture on the machine side.
Can it replace an axis drive on a MAZAK MELDAS machine without wiring changes?
In most cases it serves as a drop-in replacement within the same MDS-C1 cabinet position. Match connectors, motor family and rating, then restore parameters as required by the machine builder.
What cooling considerations apply in the cabinet?
This model uses forced-air cooling. Keep filters clean, maintain airflow paths and ensure sufficient space around the unit to manage heat under continuous duty.
| Availability | Immediate shipment |
|---|---|
| Width | 38 |
| Length | 9 |
| Height | 30 |
| Weight | 9.00 kgs |
-
