REXROTH MHD090B-035-PG1-UN AC Servo Motor Break Encoder
Starting at $1,998.00 $1,998.00
Buy online your INDRAMAT Rexroth MHD090B-035-PG1-UN AC Servo Motor from our e-store Cnc-shopping.
The Bosch Rexroth R911281235 MHD090B-035-PG1-UN is a synchronous servo motor equipped with a plain shaft and shaft seal, featuring liquid, surface, or natural cooling options. It delivers a continuous torque at standstill of 12.0 Nm and a maximum torque of 43.5 Nm, with a rotor moment of inertia of 43.0 x 10⁻⁴ kg·m². Rated current is 4.7–6.7 A (natural cooling) and 9.7 A (surface cooling), with power output up to 5.9 kW and rated voltage of 354–399 V at 200 Hz. The motor incorporates a digital absolute encoder capable of position detection beyond 4096 revolutions. The holding brake torque is 11.0 Nm. Its maximum speed is 5000 min⁻¹, and it has an IP65 protection rating. The unit has a motor length “B,” flange size of 140 mm, centering diameter of 110 mm. It is classified under insulation class F according to DIN VDE 0530 Part 1 and is suitable for ambient temperatures from -20°C to +80°C. Connections for power and feedback are provided via connectors that are turnable within a 270° range.
This INDRAMAT Rexroth MHD090B-035-PG1-UN AC Servo Motor is ready to replace your defective motor, ensuring your systems continue to run smoothly and efficiently.
Availability | Shipment within 3 days |
---|---|
Weight | 22.00 kgs |
-
