SIEMENS 6SC6506-4AA02 Spindle drive 60A

SIEMENS spindle drive reference 6SC6506-4AA02 for sale online on Cnc-shopping webstore. Cnc-shopping proposes this SIEMENS drive which is used with SIEMENS AC spindle asynchronous motor serie1PH5/6. The input voltage of this spindle drive is 380V (three-phase). The output current is 60A. The nominal power is 45kVA. This spindle drive is equiped with input fuses (80A). This SIEMENS 6SC6506-4AA02 spindle drive includes the boards 6SC6500-0UC01, 6SC6500-0NA04, 6SC6100-0GE01, 6SC6100-0GC08, 6SC6506-0AA02, the transistor module 2DI150Z-100 and the chopper module 1DI150GE-100. This SIEMENS 6SC6506-4AA02 spindle drive is ready to replace your defective SIEMENS AC spindle drive on your machine tools and is sold with a warranty.

Motor–protection circuit–breakers should be used to protect the motors. When the motor has an overload condition, it only switches a signal contact. If the motor is separated from the power module with the pulses enabled during operation, then there is the danger that the power module will destroy itself together with the control unit. Because of the harmonic oscillations in the current, set approx. 10% above the rated current. SIEMENS 6SC6506-4AA02
