SUN CHEN Sound Pneumatic Boosting Cylinder 50 Capacity 6000kgs Stroke 13mm

Buy online your SUN CHEN Sound Pneumatic Boosting Cylinder 50 Capacity 6000kgs Stroke 13mm from our US e-store Cnc-shopping USA, specialist in CNC machine-tools spare parts.

This is a pneumatic power cylinder designed for high-force clamping, pressing, and workholding applications in industrial automation and CNC machine environments. Utilizing a force-multiplication mechanism, it generates high clamping force from a standard compressed-air supply, eliminating the need for more complex hydraulic systems in many applications.

This model delivers a nominal force of 6000 kg with a 13 mm stroke, making it ideal for operations that require significant force over a short travel distance. Typical applications include fixture clamping, precision pressing, staking, swaging, light punching, and other production processes where strong and repeatable holding force is essential.

The SUN CHEN Sound Pneumatic Boosting Cylinder is widely used on CNC machining centers, lathes, automated assembly stations, and custom production fixtures. Its short-stroke design helps reduce cycle times while maintaining secure workpiece positioning during machining or assembly operations. The compact Size 50 configuration allows easy integration into existing fixtures, jigs, and retrofit installations.

Manufactured in Taiwan by CHEN SOUND INDUSTRIAL (SUN), this pneumatic boosting cylinder is built for continuous industrial use and provides reliable performance in demanding production environments. Its robust construction makes it suitable for repetitive clamping and pressing applications where consistent force and long service life are required.

In maintenance applications, the SUN CHEN Sound Pneumatic Boosting Cylinder is commonly used as a replacement for worn or leaking cylinders that can no longer maintain adequate clamping force. Replacing a faulty unit helps restore fixture performance, improve process stability, and minimize machine downtime. It is also a valuable spare part for facilities operating multiple identical fixtures or automated workholding systems.

With its 6000 kg force capacity, 13 mm stroke, and durable industrial design, the SUN CHEN Sound Pneumatic Boosting Cylinder is an effective solution for high-force pneumatic clamping and pressing applications requiring reliable, repeatable performance.

Frequently asked questions about SUN CHEN Sound Pneumatic Boosting Cylinder :

Is the 13 mm travel suitable for fixture clamping on CNC machines
Yes, the short stroke is designed for power clamping and pressing tasks where high force is required after a brief approach. It helps maintain repeatable positioning and reduces cycle time in repetitive operations.

Can this be used as a direct replacement for an existing SUN size 50 unit
In many cases yes, provided the mounting footprint, port locations and rod alignment match your current setup. Compare dimensions and stroke to confirm a drop-in replacement before installation.

What air supply is typically used
The cylinder is intended for standard industrial compressed air in shop conditions. Use clean and dry air to support seal life and consistent boosting performance.

Where is this actuator commonly installed
You will often find it in CNC workholding fixtures, press-fit stations, light punching nests and automated assembly tooling that require high clamp force with limited movement.

How should maintenance teams evaluate a failing unit
Typical signs include air leakage, reduced clamp force and incomplete stroke. Many teams keep a tested unit on hand to swap quickly, then assess the removed cylinder for possible repair service or exchange.
