TELEMECANIQUE XPSAT5110 Safety Relay

Starting at $721.50 $721.50

Manufacturer's Suggested Retail Price (11-2014): $450.00
Product condition Availability Warranty
Price
Refurbished
Ships from: USA Warehouse
stock available Shipment within 3 days Estimate my delivery
1 month Warranty - Factory return he product is under warranty for a factory return to our workshop, to be repaired or replaced, throughout its warranty period.
$721.50 $721.50
Your savings on Manufacturer's suggested retail price: -$200.00
Estimate Totals

Enter your destination to get a totals estimate.

  • Top-quality products backed by a warranty
  • Advanced technical support
  • Secure payment process with PDF invoice

Buy online your TELEMECANIQUE XPSAT5110 Safety Relay reference XPSAT5110 from our US e-store Cnc-shopping USA, specialist in CNC machine-tools spare parts.

This Schneider Electric TELEMECANIQUE module from the PREVENTA XPS-AT family supervises emergency stop circuits, guard switches and light-curtain outputs in CNC and industrial control cabinets. It provides safety-rated outputs to contactors and drive enables, making it a dependable replacement unit and CNC replacement component for maintenance, retrofit and repair tasks on the production floor.

Within a CNC cabinet the unit acts as the safety interface between field devices and the power switching chain. It connects E-stop pushbuttons, door interlocks or presence sensors to the main contactor and the drive enable loop so a verified stop is achieved before power is restored. The compact housing and clear terminal markings help technicians trace wiring quickly during troubleshooting and field replacement.

A flexible supply accepts 24 VAC or 24 VDC, which simplifies a drop-in swap during downtime without modifying cabinet control power. Output ratings cover AC-15 B300 and AC-15 C300 control duty, with DC-13 at 24 V supported up to 4 A and 2 A depending on the channel. These capabilities suit contactor coils, drive enable paths and PLC safety inputs commonly found around machining centers, turning machines and CNC routers.

Panel technicians value the consistent PREVENTA terminal layout because it aligns with existing documentation across many Schneider Electric control panels. In practice this model is used as a direct field replacement for XPS-AT references when a safety relay will not reset, trips intermittently or indicates coil faults. No programming is required since commissioning follows standard safety reset logic defined in the machine schematic.

XPSAT5110 by TELEMECANIQUE in the Schneider Electric PREVENTA XPS-AT series, manufactured in France.

Listed under our catalog section TELEMECANIQUE Operator panels while functionally serving as a safety relay for CNC and industrial panels.

Primary role in the cabinet is to monitor E-stop chains, gate interlocks and presence sensors, then provide safety-rated contacts to the main contactor and drive enable circuits.

Typical use cases include milling and turning equipment, CNC routers and retrofit panels where a drop-in replacement or spare part is required without altering the control power supply.

Key operating data for practical selection: supply options 24 VAC or 24 VDC, control-duty categories AC-15 B300 and C300, DC-13 at 24 V up to 4 A and 2 A depending on the channel, consistent PREVENTA terminal designation and no programming requirement.

On real machine-tool lines this reference is commonly stocked as a ready replacement unit to cut downtime when a safety module fails to reset or exhibits nuisance trips. Keeping a sealed unit in industrial spare inventory helps maintenance teams restore machine operation quickly since wiring and terminal layout match established PREVENTA practice.

For planned overhauls on legacy CNCs that still run Schneider Electric safety circuits, this model fits preventive replacement strategies and supports long-term uptime. It also integrates well in retrofit projects where maintaining familiar PREVENTA wiring conventions streamlines documentation and signoff.

Each unit is functionally checked on dedicated safety relay benches and simulators by skilled engineers, then packed with protective materials for industrial shipping and supplied with warranty. Many stocked items ship directly from our Florida facility, with fast dispatch depending on availability.

This reference can serve as an emergency spare for older panels built around the PREVENTA XPS-AT line. Cnc-shopping USA supports sourcing of obsolete parts and can propose repair service or an exchange service when feasible based on the condition of the returned unit, helping maintain machine uptime on legacy installations.

Frequently asked questions about XPSAT5110:

What input supply options are supported?
The module operates from either 24 VAC or 24 VDC, which allows a direct swap in most CNC control cabinets without changing the control power source.

How are the outputs rated and what can they switch?
Outputs are rated for AC-15 B300 and AC-15 C300 control duty, with DC-13 at 24 V up to 4 A and 2 A. These ratings suit contactor coils, drive enables and safety I/O commonly used around CNC drives and PLCs.

Is it a direct field replacement for PREVENTA XPS-AT references?
Yes, it aligns with the XPS-AT series design so terminal layout and function match typical PREVENTA wiring. Always verify against your panel drawings before energizing.

Where is it usually installed in a CNC safety chain?
It is commonly placed in the E-stop chain and used to monitor door switches and light-curtain outputs, feeding the main contactor and the drive enable path of machining centers and turning machines.

Does it require programming during commissioning?
No programming is needed. Commissioning follows the machine schematic with correct wiring and standard safety reset logic.
