YASKAWA SGDH-04AE Servopack Amplifier 200V 0.4kW

Starting at $832.50 $832.50

Product condition Availability Warranty
Price
New
Ships from: USA Warehouse
stock available Shipment within 3 days
6 months Warranty - Factory return he product is under warranty for a factory return to our workshop, to be repaired or replaced, throughout its warranty period.
$832.50 $832.50
Estimate Totals

Enter your destination to get a totals estimate.

  • Top-quality products backed by a warranty
  • Advanced technical support
  • Secure payment process with PDF invoice

Buy online your YASKAWA SGDH-04AE Servopack Amplifier 200V 0.4kW reference SGDH-04AE from our US e-store Cnc-shopping USA, specialist in CNC machine-tools spare parts.

This YASKAWA SIGMA II servo amplifier is a panel-mounted drive used for torque, speed and position control on 0.4 kW axes across CNC machine-tools and automated equipment. It serves as a dependable replacement unit for Sigma II 200 V installations where a compact, reliable servo drive is required. Commonly sourced as a spare part for maintenance teams, it supports fast field replacement to restore machine uptime on production floors.

Engineered for the 200-230 VAC class, the SGDH-04AE supplies three-phase output matched to 0.4 kW Sigma II motors. Typical integration uses the standard CN1 control interface seen across the Sigma II family, allowing straightforward connection to CNC controls or PLC motion cards already present in the cabinet. Built-in diagnostics help technicians verify status and alarms during commissioning or post-repair checks.

Electrical characteristics align with 0.4 kW axes found on small X, Y, Z or auxiliary feed drives, loaders, and indexing functions. Input power is rated at 3-phase 200-230 V, 50/60 Hz, 5.5 A, and the drive delivers a 3-phase 0-230 V output up to 2.8 A within a 0-300 Hz range. This makes it a practical drop-in for machines originally configured with YASKAWA SIGMA II hardware where cabinet space and wiring harnesses are already standardized for SGDH units.

Manufactured in Japan, the SGDH-04AE is commonly used in CNC lathes, machining centers, grinders, packaging modules and gantry axes that specify a 200 V Sigma II drive at the 400 W level. Its compact footprint and standardized connectors simplify removal and replacement during planned maintenance or unplanned downtime events.

Reference: SGDH-04AE

Manufacturer: YASKAWA

Product type: YASKAWA CACR Servo drives

Main function: 200 V servo amplifier for 0.4 kW Sigma II motor control

Applications: CNC axes on lathes, machining centers, grinders, handling and packaging equipment requiring a 0.4 kW 200 V servo channel

Key technical data: SIGMA II 200 V series, 0.4 kW rating, AC input 3-phase 200-230 V 5.5 A 50/60 Hz, AC output 3-phase 0-230 V 2.8 A 0-300 Hz, panel-mounted Servopack form factor, made in Japan, refurbished and tested unit with functional warranty

In the field this model is selected to replace a failed 0.4 kW axis amplifier without modifying cabinet wiring or motor selection. Maintenance teams typically keep one on the shelf as a stocked spare for Sigma II machines so a faulty drive can be swapped and the machine returned to service with minimal downtime. For retrofit or rebuild projects, it is often used as a drop-in replacement where the existing 200 V motor and feedback remain unchanged.

Each refurbished SGDH-04AE from Cnc-shopping USA is verified by skilled engineers on dedicated CNC simulators with matched servo motors, covering command, feedback and load test checks before shipment. Units are professionally packaged for industrial transport and supplied with a functional warranty. Many stocked items ship directly from our Florida facility, depending on availability.

This model is frequently needed as an emergency spare on legacy Sigma II installations. Cnc-shopping USA supports sourcing of obsolete parts and can assist with repair service or an exchange service when appropriate, helping extend machine life and stabilize your spare inventory planning.

Frequently asked questions about SGDH-04AE:

Is the SGDH-04AE a one-for-one replacement for a failed 0.4 kW Sigma II drive?
Yes, when the part code matches and the machine is configured for a 200-230 V Sigma II 0.4 kW axis. Verify motor rating, control wiring on CN1, and restore machine parameters from your backup after installation if required by your procedure.

What input power does this model require?
It operates on 3-phase 200-230 VAC at 50/60 Hz with an input current rating of 5.5 A. Ensure the cabinet supply and protection devices meet these values before energizing the drive.

Which motors are typically paired with this unit?
It is intended for SIGMA II 200 V motors in the 0.4 kW class. Match the motor’s nameplate current and feedback to the drive rating and confirm compatibility against your machine documentation.

Can it be used as a spare across multiple machines?
Many maintenance teams keep one SGDH-04AE as a spare part for any axis that uses a 0.4 kW Sigma II 200 V motor. Always check the OEM bill of materials and parameter sets for each machine before swapping drives.

More Information
AvailabilityShipment within 3 days
Weight4.00 kgs
