YASKAWA SGM7G-30DFF6F AC Servo Motor 400V 1500-3000rpm 11.9A 2.9kW

Buy online your YASKAWA SGM7G-30DFF6F AC Servo Motor from our e-store Cnc-shopping.

The YASKAWA SGM7G-30DFF6F AC Servo Motor is a high-performance servo motor designed for industrial applications and machine tools. It operates with an electrical supply of 400 V and delivers a nominal output of 2.9 kW. Its shaft features a keyway and key, while its incremental encoder with 24-bit resolution ensures optimal precision.

This motor includes options such as a dust seal, making it suitable for demanding environments. Its compact dimensions are 246 mm in height, 180 mm in width, and 241 mm in depth, with a nominal torque of 18.6 Nm and a maximum instantaneous torque of 45.1 Nm. It offers a nominal speed of 1500 rpm and a maximum speed of 3000 rpm.

The motor flange has a diameter of 180 mm, with a shaft end measuring 35 mm in diameter and 76 mm in length, ensuring compatibility with various industrial equipment. This motor is ideal for maintenance, repair, and optimizing the performance of CNC machines.

This YASKAWA SGM7G-30DFF6F AC Servo motor is ready to replace your defective servo motor and comes with a warranty, making it a reliable choice for industries.
