A06B-6114-H105 FANUC Servo amplifier Alpha iSV 1-80 FSSB

Buy online your FANUC A06B-6114-H105 Servo Amplifier Module directly from our online store in the USA. Ready to replace your faulty FANUC A06B-6114-H105 with ALARM 01/02/05/06/F/P/, Alarm 8 (IPM) 8. (IPM SVM) This FANUC Servo amplifier module type FANUC iSV1-80 FSSB is part of the FANUC Alpha I series and is designed to deliver precision control for CNC systems.

Each FANUC A06B-6114-H105 module is tested and, if refurbished, restored to its original factory specifications. A complete inspection report is provided upon shipment, ensuring the product is in optimal working condition. You can see examples of the testing process in the photos. Get a FANUC A06B-6114-H105 from a reliable supplier that thoroughly tests its FANUC servo amplifiers and refurbishes them by replacing components such as fans, capacitors, HCPL, and more

The FANUC A06B-6114-H105 Servo amplifier module comes with a warranty, offering peace of mind and minimizing downtime in your industrial operations.

Frequently Asked Questions (FAQ) about FANUC A06B-6114-H105 Servo Amplifier Modules

What causes an alarm on the FANUC A06B-6114-H105 module?
Alarms may occur due to overheating, improper connections, or power supply issues. Check the module’s cooling system, inspect all cables, and ensure the A06B-6110 power supply provides the correct DC voltages and meets the required specifications. If the problem persists, our tested FANUC A06B-6114-H105 module is available for quick replacement from our US warehouse.

Can I use the FANUC A06B-6114-H105 on older CNC systems?
Yes, the FANUC A06B-6114-H105 is compatible with most FANUC i systems, including older models such as 16i, 18i, 21i (Model A or B

How do I resolve overheating issues on the FANUC A06B-6114-H105?
Overheating may be caused by inadequate ventilation or excessive load. Ensure the module is installed in a well-ventilated environment and verify that the load does not exceed its rated capacity. If the issue persists, consider replacing the module with our tested FANUC A06B-6114-H105, available from our US warehouse.

What should I do if the FANUC A06B-6114-H105 module fails to initialize?
Initialization issues may occur due to FSSB issues. Check the wiring connections and update the firmware if necessary. If the problem continues, our refurbished FANUC A06B-6114-H105 module is ready for shipment to minimize downtime.

Is the FANUC A06B-6114-H105 module covered by a warranty?
Yes, all FANUC A06B-6114-H105 modules purchased from our online store in the USA come with a warranty. This ensures peace of mind and guarantees the product’s reliability.

How can I maintain the performance of the FANUC A06B-6114-H105 module?
To maintain optimal performance, clean the module regularly, periodic maintenance of the Fans, and monitor its operating conditions.

FANUC A06B-6114-H105 Servo Amplifier Module - Alarm Codes and Troubleshooting

The FANUC A06B-6114-H105 Servo Amplifier Module is a reliable component in the FANUC Alpha I series. However, it may encounter certain alarm codes that require immediate attention or replacement. Below is a detailed guide to common alarm codes, their meanings, and troubleshooting steps.

Common FANUC A06B-6114-H105 Alarm Codes and Troubleshooting Steps

• Alarm Code 1: Internal Cooling Fan Stopped
  • Check for foreign material in the fan.
  • Ensure the fan connector is attached correctly.
  • If the issue persists, replace the fan.
  • If the fan replacement does not resolve the issue, replace the SVM module.
• Alarm Code 2: Control Power Supply Under Voltage
  • Check the three-phase input voltage (must not be lower than 85% of the rated input voltage).
  • Verify the 24V power supply output from the PSM (normally above 22.8V).
  • Inspect the connector and cable (CXA2A/B).
  • Replace the SVM module if necessary.
• Alarm Code 5: DC Link Under Voltage
  • Ensure the screws for the DC link connection cable are tight.
  • If multiple modules experience this alarm, troubleshoot the power supply module.
  • If only one module is affected, replace the SVM module.
• Alarm Code 6: Overheat
  • Verify the motor is operating within its continuous rating.
  • Check the cabinet's cooling capacity (inspect fans and filters).
  • Ensure the ambient temperature is not too high.
  • Replace the SVM module if overheating persists.
• Alarm Code F: Cooling Fan Stopped (Radiator)
  • Inspect for foreign material in the fan.
  • Ensure the fan connector is properly attached.
  • Replace the fan if necessary.
  • If unresolved, replace the SVM module.
• Alarm Code P: Communication Error Between Amplifier and Module
  • Check the connector and cable (CXA2A/B).
  • Replace the control printed-circuit board if needed.
  • Replace the SVM module if the issue persists.
• Alarm Code 8: DC Link Current Alarm
  • Disconnect the motor power leads and release the SVM from emergency stop condition.
  • If insulation between PE and motor power leads is deteriorated, check the motor or power leads.
  • Replace the motor or power lead as necessary.
  • If unresolved, replace the SVM module.
• Alarm Code 8.9.A: IPM Alarm (OH)
  • Ensure the heat sink cooling fan is running.
  • Verify the motor is operating within its continuous rating.
  • Check the cabinet's cooling capacity (inspect fans and filters).
  • Ensure the ambient temperature is not too high.
  • Replace the SVM module if necessary.
• Alarm Code bcd: Abnormal Inverter Motor Current
  • Verify servo parameters as per the FANUC AC Servo Motor i series Parameter Manual.
  • If abnormal motor current occurs during rapid acceleration/deceleration, adjust the acceleration/deceleration time constant.
  • Check insulation between PE and motor power leads.
  • Replace the motor, power lead, or SVM module as necessary.

Why Replace the FANUC A06B-6114-H105?

If the troubleshooting steps above do not resolve the alarm conditions, it is likely that the FANUC A06B-6114-H105 Servo Amplifier Module requires replacement. Our US warehouse offers tested and refurbished modules, ensuring fast delivery and minimal downtime for your CNC systems.

Order Now from Our US Warehouse

Don’t let alarm codes disrupt your operations. Replace your FANUC A06B-6114-H105 with a fully tested and guaranteed module from our online store in the USA. Fast shipping and expert support are available to ensure your CNC systems continue to run smoothly.
